Save costly shop repairs with accurate, on-site boring and welding, all with one easy setup. Mactech’s simple to operate BB2250 Boring Bar is the solution for any bore repair that needs to be done right away. Teamed with the BOA Bore Welder, the BB2250 is the one-setup solution for many of your on-site repairs. Powerful, accurate machining gets your equipment up and running fast, reducing your downtime and saving you money. Or, match your BB2250 with one or all of the many useful accessories available. The goanywhere narrow profile fits in the tightest work areas. Custom setups are our specialty, give us a call and we will make a system suited just for your application.

LINE BORING EQUIPMENT GALLERY

MACTECH'S BB2250 BORING BAR SYSTEMS AVAILABLE

• 48" long
• 72" long
• 96" Long

CAPABILITIES

The BB2250 Boring Bar is capable of machining

2-1/2” to 16” (64 to 406 mm) inside diameters.

BORING BAR

2-1/4” diameter (57 mm) chrome plated bar. Square tool holder broaches accept 1/2” (12 mm) square tooling. Boring bars are available in 48”, 72”, 96”, and 144” standard lengths (1219, 1829, 2438, and 3658 mm).

DRIVE SYSTEM

The BB2250 drive system includes a 6:1 reduction gear drive, available with hydraulic or electric motor.

FEED RATE

0” to 0.015” axial feed per revolution

(0 to 0.4 mm axial feed per revolution)

FEED SCREWS

Steel, 1-4 Acme thread double-start feed screw.

FEED SCREWS

12” travel (305 mm) - 20 inch long (508 mm) feed screw.

24” travel (610 mm) - 32 inch long (813 mm) feed screw.

TOOLING

The BB2250 Boring Bar tool holders accept

standard 1/2” (12 mm) square tool bits.

NEED TO RENT A LINE BORING EQUIPMENT?
